THX ULTRA Certified 200mm Subwoofer
Certified to THX ULTRA2 and THX SELECT2 standards, the formidable Ci200QSb-THX in-wall subwoofer delivers deep bass and theatre thumping output capabilities, matched to the uncanny ability to deliver all the drama and emotional intensity of full theatre sound quality.
Ci200QSb-THX
Certified to THX ULTRA2 and THX SELECT2 standards, the
formidable Ci200QSb-THX in-wall subwoofer delivers deep bass and theatre thumping output capabilities,
matched to the uncanny ability to deliver all the drama and emotional intensity of full theatre sound
quality. With a powerful high-output 200mm (8in.) sub-bass driver, the Ci200QSb-THX can be used in
passive mode to supplement the LF output of KEF’s Ci series in-wall or in-ceiling speakers. In Active
mode, when 2 pair of the Ci200QSb-THX subwoofer are powered by the powerful 250Wx 2 KEF KASA500 System
Amplifier the performance meets THX Select2 specification. When 4 pair of the Ci200QSb-THX are powered
by 2 KEF KASA500 System Amplifiers the performance meets THX Ultra2 specification.
細節
FEATURES
THX Certified Ultra2 / Select2
200mm (8in.) woofer unit with extended bass response
可塗色超薄邊飾 (UTB) 和磁性網罩與空間裝飾融於一體
安裝快捷簡便，可以通過狗腿彎孔固定於大多數表面
Can be used in passive mode with internal crossover or active mode with KEF’s KASA500 System Amplifier for THX certified performance
Sold in Pairs
200mm (8in.) woofer unit with extended bass response
可塗色超薄邊飾 (UTB) 和磁性網罩與空間裝飾融於一體
安裝快捷簡便，可以通過狗腿彎孔固定於大多數表面
Can be used in passive mode with internal crossover or active mode with KEF’s KASA500 System Amplifier for THX certified performance
Sold in Pairs
技術規格
阻抗
6
Ohm - Passive Mode (Crossover "ON")
N/A - Active Mode (KASA500)
N/A - Active Mode (KASA500)
靈敏度
85dB - Passive Mode (Crossover "ON")
N/A - Active Mode (KASA500)
N/A - Active Mode (KASA500)
分頻點
100Hz - Passive Mode (Crossover "ON")
N/A - Active Mode (KASA500)
N/A - Active Mode (KASA500)
頻率響應
40Hz-100Hz - Passive Mode (Crossover "ON")
18Hz-140Hz - Active Mode (KASA500)
18Hz-140Hz - Active Mode (KASA500)
驅動單元M
低音: 200mm (8 in.)
建議輸出功率
10-150W - Passive Mode (Crossover "ON")
KASA500 - Active Mode (KASA500)
KASA500 - Active Mode (KASA500)
產品外部尺寸
Diameter: 273 x 273 x 106 mm (10.75 x 10.75 x 4.17 in.)
圖樣尺寸
238 x 238 mm (9.37 x 9.37 in.)
安裝厚度
天花厚度(最大):40 毫米(1.58 英寸)
天花厚度(最小):6 毫米(0.24 英寸)
天花厚度(最小):6 毫米(0.24 英寸)
表面安裝深度
101.6mm (4 in.)
適配框架
RIF200S
淨重
3.3kg (7.28 lbs)
測量單位
*以每個計算
KEF reserves the right, in line with
continuing research and development, to amend or change specifications. E&OE.
更多資訊，請瀏覽 Ci 軟件下載 。
